Description

Nightforce ATACR FDE – F1 1-8×24 – Mil – FC-DMx – C672 :

Designed and built to be the ultimate low-power variable riflescope. It includes pristine ED glass, bright daylight illumination, an intelligent reticle, very low-profile adjustments and bomb-proof reliability, with a field of view at 1x equivalent to open sights. but vastly more precise. It measures just over 10 inches in length and weighs 21 ounces, with a streamlined profile. The daylight visible, center red dot allows for rapid engagements like a red-dot sight. Unlike a red-dot, however, the 1-8x provides up to 8x zoom to help locate, identify and engage targets at the maximum effective range of most rifles. The intelligent FC-DM first focal plane reticle provides precise hold and hold-off points. The low-profile turrets are capped to prevent accidental adjustment and offer true .1 Mil-Radian adjustment. To aid in fast magnification adjustments, an integrated Power Throw Lever (PTL) is included.

Function Design:

• First focal plane reticle placement
• Power throw lever allows instant magnification
• Fully Multicoated ED glass
• 34 mm tube allows 30 Mils of Elevation Windage adjustment
• New, more highly visible magnification markings
• Hi-speed threads for faster diopter adjustment
• Capped windage adjustment, to avoid accidental adjustments
• Nightforce intelligent reticle

Magnification Range – 1-8x

Focal Plane – First Focal Plane (F1/FFP)

Body Tube Diameter – 34mm

Overall Length – 10.1in/256 mm

Mounting Length – 5.7 in/144 mm

Weight – 21.0 oz/595 g

Click Value – .1 MRAD

Internal Adjustment Range – E: 30 MRAD W: 30 MRAD

Parallax Adjustment – Fixed @ 125 m

Eye Relief – 3.7 in/95 mm

Field of View @ 100 yd or m – 1x: 96.1 ft/32.0 m 8x: 13.1 ft/4.4 m

Exit Pupil – 1x: 11.3 mm 8x: 3.2 mm

Illumination – Daylight visible, Externally adjustable, Two night vision settings

Elevation Feature – Capped, finger-adjustable

Power Throw Lever – Standard
